# Lab 12: Regular Expressions, BNF

*Due by 11:59pm on Wednesday, November 17.*

## Starter Files

Download lab12.zip. Inside the archive, you will find starter files for the questions in this lab, along with a copy of the Ok autograder.

# Topics

Consult this section if you need a refresher on the material for this lab. It's okay to skip directly to the questions and refer back here should you get stuck.

## Regular Expressions

Regular expressions are a way to describe sets of strings that meet certain criteria, and are incredibly useful for pattern matching.

The simplest regular expression is one that matches a sequence of characters, like `aardvark`

to match any "aardvark" substrings in a string.

However, you typically want to look for more interesting patterns. We recommend using an online tool like regexr.com for trying out patterns, since you'll get instant feedback on the match results.

### Character classes

A character class makes it possible to search for any one of a set of characters. You can specify the set or use pre-defined sets.

Class | Description |
---|---|

`[abc]` |
Matches a, b, or c |

`[a-z]` |
Matches any character between a and z |

`[^A-Z]` |
Matches any character that is not between A and Z. |

`\w` |
Matches any "word" character. Equivalent to `[A-Za-z0-9_]` |

`\d` |
Matches any digit. Equivalent to `[0-9]` . |

`[0-9]` |
Matches a single digit in the range 0 - 9. Equivalent to `\d` |

`\s` |
Matches any whitespace character (spaces, tabs, line breaks). |

`.` |
Matches any character besides new line. |

Character classes can be combined, like in `[a-zA-Z0-9]`

.

### Combining patterns

There are multiple ways to combine patterns together in regular expressions.

Combination | Description |
---|---|

`AB` |
A match for A followed immediately by one for B. Example: `x[.,]y` matches "x.y" or "x,y" |

`A|B` |
Matches either A or B. Example: `\d+|Inf` matches either a sequence containing 1 or more digits or "Inf" |

A pattern can be followed by one of these quantifiers to specify how many instances of the pattern can occur.

Quantifier | Description |
---|---|

`*` |
0 or more occurrences of the preceding pattern. Example: `[a-z]*` matches any sequence of lower-case letters or the empty string. |

`+` |
1 or more occurrences of the preceding pattern. Example: `\d+` matches any non-empty sequence of digits. |

`?` |
0 or 1 occurrences of the preceding pattern. Example: `[-+]?` matches an optional sign. |

`{1,3}` |
Matches the specified quantity of the preceding pattern. {1,3} will match from 1 to 3 instances. {3} will match exactly 3 instances. {3,} will match 3 or more instances. Example: `\d{5,6}` matches either 5 or 6 digit numbers. |

### Groups

Parentheses are used similarly as in arithmetic expressions, to create groups. For example, `(Mahna)+`

matches strings with 1 or more "Mahna", like "MahnaMahna". Without the parentheses, `Mahna+`

would match strings with "Mahn" followed by 1 or more "a" characters, like "Mahnaaaa".

### Anchors

`^`

- Matches the beginning of a string. Example:
`^(I|You)`

matches I or You at the start of a string.

- Matches the beginning of a string. Example:
`$`

- Normally matches the empty string at the end of a string or just before a newline at the end of a string. Example:
`(\.edu|\.org|\.com)$`

matches .edu, .org, or .com at the end of a string.

- Normally matches the empty string at the end of a string or just before a newline at the end of a string. Example:
`\b`

- Matches a "word boundary", the beginning or end of a word. Example:
`s\b`

matches s characters at the end of words.

- Matches a "word boundary", the beginning or end of a word. Example:

### Special characters

The following special characters are used above to denote types of patterns:

`\ ( ) [ ] { } + * ? | $ ^ .`

That means if you actually want to match one of those characters, you have to *escape* it using a backslash. For example, `\(1\+3\)`

matches "(1 + 3)".

### Using regular expressions in Python

Many programming languages have built-in functions for matching strings to regular expressions. We'll use the [Python re module] in 61A, but you can also use similar functionality in SQL, JavaScript, Excel, shell scripting, etc.

The search method searches for a pattern anywhere in a string:

`re.search(r"(Mahna)+", "Mahna Mahna Ba Dee Bedebe")`

That method returns back a match object, which is considered truth-y in Python and can be inspected to find the matching strings.

For more details, please consult the re module documentation or the re tutorial.

## BNF

Backus-Naur Form (BNF) is a syntax for describing a context-free grammar. It was invented for describing the syntax of programming languages, and is still commonly used in documentation and language parsers. EBNF is a dialect of BNF which contains some convenient shorthands.

An EBNF grammar contains symbols and a set of recursive production rules. In 61A, we are using the Python Lark library to write EBNF grammars, which has a few specific rules for grammar writing.

There are two types of symbols: Non-terminal symbols can expand into non-terminals (including themselves) or terminals. In the Python Lark library, non-terminal symbols are always lowercase. Terminal symbols can be strings or regular expressions. In Lark, terminals are always uppercase.

Consider these two production rules:

```
numbers: INTEGER | numbers "," INTEGER
INTEGER: /-?\d+/
```

The symbol `numbers`

is a non-terminal with a recursive production rule. It corresponds to either an `INTEGER`

terminal or to the `numbers`

symbol (itself) plus a comma plus an `INTEGER`

terminal. The `INTEGER`

terminal is defined using a regular expression which matches any number of digits with an optional - sign in front.

This grammar can describe strings like:

```
10
10,-11
10,-11,12
```

And so on, with any number of integers in front.

A grammar should also specify a start symbol, which corresponds to the whole expression being parsed (or the whole sentence, for a spoken language).

For the simple example of comma-separated numbers, the start symbol could just be the numbers terminal itself:

```
?start: numbers
numbers: numbers "," INTEGER | INTEGER
INTEGER: /-?\d+/
```

EBNF grammars can use these shorthand notations for specifying how many symbols to match:

EBNF Notation | Meaning | Pure BNF Equivalent |
---|---|---|

item* | Zero or more items | items: | items item |

item+ | One or more items | items: item | items item |

[item] item? |
Optional item | optitem: | item |

Lark also includes a few handy features:

- You can specify tokens to complete ignore by using the ignore directive at the bottom of a grammar. For example,
`%ignore /\s+/`

ignores all whitespace (tabs/spaces/new lines). - You can import pre-defined terminals for common types of data to match. For example, %import common.NUMBER imports a terminal that matches any integer or decimal number.

Using all of that, here's an EBNF grammar that corresponds to the Calculator language:

```
start: calc_expr?
calc_expr: NUMBER | calc_op
calc_op: "(" OPERATOR calc_expr* ")"
OPERATOR: "+" | "-" | "*" | "/"
%ignore /\s+/
%import common.NUMBER
```

You can paste that into code.cs61a.org and then input Calculator expressions in the interpreter to see their parse trees. Try it!

# Questions

## Regular Expressions

### Q1: Calculator Ops

Write a regular expression that parses strings written in the 61A Calculator language and returns any expressions which have two numeric operands, leaving out the parentheses around them.

```
import re
def calculator_ops(calc_str):
"""
Finds expressions from the Calculator language that have two
numeric operands and returns the expression without the parentheses.
>>> calculator_ops("(* 2 4)")
['* 2 4']
>>> calculator_ops("(+ (* 3 (+ (* 2 4) (+ 3 5))) (+ (- 10 7) 6))")
['* 2 4', '+ 3 5', '- 10 7']
>>> calculator_ops("(* 2)")
[]
"""
return re.findall(__________, calc_str)
```

Use Ok to test your code:

`python3 ok -q calculator_ops`

## BNF

### Q2: Calculator BNF

Consider this BNF grammar for the Calculator language:

```
?start: calc_expr
?calc_expr: NUMBER | calc_op
calc_op: "(" OPERATOR calc_expr* ")"
OPERATOR: "+" | "-" | "*" | "/"
%ignore /\s+/
%import common.NUMBER
```

Let's understand and modify the functionality of this BNF with a few questions.

Use Ok to test your understanding:

`python3 ok -q ebnf-grammar-wwpd -u`

### Q3: Linked List BNF

For the next two problems, you can test your code on code.cs61a.org by adding the following line at the beginning before the problem's skeleton code:

`?start: link -- replace link with tree_node for the next question`

In this problem, we're going to define a BNF that parses integer Linked Lists created in Python. We won't be handling `Link.empty`

.

For reference, here are some examples of Linked Lists:

*Your implementation should be able to handle nested Linked Lists, such as the third example below.*

`Link(2)`

`Link(12, Link(2))`

`Link(5, Link(7, Link(Link(8, Link(9)))))`

```
link: "null"
?link_first: "null"
?link_rest: "null"
%ignore /\s+/
%import common.NUMBER
```

Use Ok to test your code:

`python3 ok -q linked_list`

### Q4: Tree BNF

Now, we will define a BNF to parse Trees with integer leaves created in Python.

Here are some examples of Trees:

*Your implementation should be able to handle Trees with no branches and one or more branches.*

`Tree(2)`

`Tree(6, [Tree(1), Tree(3, [Tree(1), Tree(2)])])`

```
tree_node: "null"
?label: "null"
branches: "null"
%ignore /\s+/
%import common.NUMBER
```

Use Ok to test your code:

`python3 ok -q tree`
