# Discussion 11: Interpreters

# Discussion 11 Vitamin

To encourage everyone to watch or attend discussion orientation, we have created small discussion vitamins. If you complete 5 of the 6 vitamins, you can earn one point of extra credit added to your final grade in the course. Please answer all of the questions in this form by **Thursday at 11:59 PM**.

# Calculator

An interpreter is a program that understands other programs. Today, we will explore how to build an interpreter for Calculator, a simple language that uses a subset of Scheme syntax.

The Calculator language includes only the four basic arithmetic operations:
`+`

, `-`

, `*`

, and `/`

. These operations can be nested and can take any numbers
of arguments. A few examples of calculator expressions and their corresponding
values are shown below.

```
calc> (+ 2 2)
4
calc> (- 5)
-5
calc> (* (+ 1 2) (+ 2 3))
15
```

The reader component of an interpreter parses input strings and
represents them as data structures in the implementing language. In this case,
we need to represent Calculator expressions as Python objects. To represent
numbers, we can just use Python numbers. To represent the names of the
arithmetic procedures, we can use Python strings (e.g. `'+'`

).

Call expressions are a bit more complicated. Like Scheme call expressions,
Calculator call expressions look just like Scheme lists. For example,
to construct the expression `(+ 2 3)`

in Scheme, we would do the following:

```
scm> (cons '+ (cons 2 (cons 3 nil)))
(+ 2 3)
```

To represent Scheme lists in Python, we will use the `Pair`

class.
A `Pair`

instance holds exactly two elements. Accordingly, the `Pair`

constructor takes in two arguments, and to make a list we must nest calls to
the constructor and pass in `nil`

as the second element of the last pair.
Note that in our implementation, `nil`

is bound to a special user-defined
object that represents an empty list, whereas `nil`

in Scheme is actually
an empty list.

```
>>> Pair('+', Pair(2, Pair(3, nil)))
Pair('+', Pair(2, Pair(3, nil)))
```

Each `Pair`

instance has two instance attributes: `first`

and `rest`

,
which are bound to the first and second elements of the pair
respectively.

```
>>> p = Pair('+', Pair(2, Pair(3, nil)))
>>> p.first
'+'
>>> p.rest
Pair(2, Pair(3, nil))
>>> p.rest.first
2
```

`Pair`

is very similar to `Link`

, the class we developed for
representing linked lists -- they have the same attribute names `first`

and `rest`

and are represented very similarly.
Here's an implementation of what we described:

```
class Pair:
"""Represents the built-in pair data structure in Scheme."""
def __init__(self, first, rest):
self.first = first
if not scheme_valid_cdrp(rest):
raise SchemeError("cdr can only be a pair, nil, or a promise but was {}".format(rest))
self.rest = rest
def map(self, fn):
"""Maps fn to every element in a list, returning a new
Pair.
>>> Pair(1, Pair(2, Pair(3, nil))).map(lambda x: x * x)
Pair(1, Pair(4, Pair(9, nil)))
"""
assert isinstance(self.rest, Pair) or self.rest is nil, \
"rest element in pair must be another pair or nil"
return Pair(fn(self.first), self.rest.map(fn))
def __repr__(self):
return 'Pair({}, {})'.format(self.first, self.rest)
```

```
class nil:
"""Represents the special empty pair nil in Scheme."""
def map(self, fn):
return nil
def __getitem__(self, i):
raise IndexError('Index out of range')
def __repr__(self):
return 'nil'
nil = nil() # this hides the nil class *forever*
```

## Questions

### Q1: From Pair to Calculator

Write out the Calculator expression with proper syntax that
corresponds to the following `Pair`

constructor calls. Also,
draw out a box and pointer diagram corresponding to each input.

`>>> Pair('+', Pair(1, Pair(2, Pair(3, Pair(4, nil)))))`

`>>> Pair('+', Pair(1, Pair(Pair('*', Pair(2, Pair(3, nil))), nil)))`

### Q2: Using Pair

Answer the following questions about a `Pair`

instance
representing the Calculator expression `(+ (- 2 4) 6 8)`

.

Write out the Python expression that returns a `Pair`

representing the given expression:

Draw a box and pointer diagram corresponding to the Pair:

```
.
.
.
.
```

What is the operator of the call expression?

If the `Pair`

you constructed in the previous part was bound to the name `p`

,
how would you retrieve the operator?

What are the operands of the call expression?

If the `Pair`

you constructed was bound to the name `p`

, how would
you retrieve a list containing all of the operands?

How would you retrieve only the first operand?

# Evaluation

The evaluation component of an interpreter determines the type of an expression and executes corresponding evaluation rules.

Here are the evaluation rules for the three types of Calculator expressions:

**Numbers**are self-evaluating, and can be thought of as primitives. For example, the numbers 3.14 and 165 just evaluate to themselves.**Names**are looked up in the`OPERATORS`

dictionary. In this dictionary, each name (e.g.`'+'`

) is bound to a corresponding function in Python that does the appropriate operation on a list of numbers (e.g.`sum`

).**Call expressions**are evaluated the same way you've been doing them all semester:**Evaluate**the operator, which evaluates to a function.**Evaluate**the operands from left to right.**Apply**the function to the value of the operands.

The function `calc_eval`

takes in a Calculator expression represented
in Python and implements each of these rules:

```
def calc_eval(exp):
"""Evaluates a Calculator expression represented as a Pair."""
if isinstance(exp, Pair): # Call expressions
fn = calc_eval(exp.first)
args = list(exp.rest.map(calc_eval))
return calc_apply(fn, args)
elif exp in OPERATORS: # Names
return OPERATORS[exp]
else: # Numbers
return exp
```

`calc_eval`

is recursive! In order to evaluate call
expressions, we must call `calc_eval`

on the operator and each of the
operands.

The `apply`

step in the Calculator language is straight-forward since we only
have primitive procedures. This step will be more complex in the Scheme project
since the procedures may include user-defined procedures.

Given the Python function that implements the appropriate Calculator operation
and a Python list of numbers, the `calc_apply`

function simply calls
the function on the arguments, and regular Python evaluation rules take place.

```
def calc_apply(fn, args):
"""Applies a Calculator operation to a list of numbers."""
return fn(args)
```

## Questions

### Q3: Counting Eval and Apply

How many calls to `calc_eval`

and `calc_apply`

would it
take to evaluate each of the following Calculator expressions?

`> (+ 2 4 6 8)`

`> (+ 2 (* 4 (- 6 8)))`

### Q4: New Operators

Suppose we want to add handling for comparison operators `>`

,
`<`

, and `=`

as well as `and`

expressions to our
Calculator interpreter. These should work the same way they do in Scheme.

```
calc> (and (= 1 1) 3)
3
calc> (and (+ 1 0) (< 1 0) (/ 1 0))
#f
```

i. Are we able to handle expressions containing the comparison operators
(such as `<`

, `>`

, or `=`

) with the existing implementation of `calc_eval`

?
Why or why not?

ii. Are we able to handle `and`

expressions with the existing
implementation of `calc_eval`

? Why or why not?

Hint:Think about the rules of evaluation we've implemented in`calc_eval`

. Is anything different about`and`

?

iii. Now, complete the implementation below to handle `and`

expressions. You may assume the conditional operators (e.g. `<`

, `>`

,
`=`

, etc) have already been implemented for you.

# Interpreters Tutorial Discussions

### Q5: (Tutorial) Interpreters Review

Discuss the follow questions with your tutorial group - they will be helpful for your understanding of the Scheme project! If you wish to take notes, we recommend you take notes on a separate document so it won't accidentally get erased.

What are the four parts of an interpreter (Hint: what does REPL stand for)? What does each part do? What parts did you work on implementing in the discussion?

For the Calculator interpreter implemented in discussion, for the following executed code, what would be the input into the "Read" portion of the interpreter?

```
calc> (+ 2 3)
5
```

What would be the output of the "Read" portion for the same code?

How does the evaluate stage work in Calculator? How do we know if an input into `calc_eval`

is a call expression?

# Scheme Lists

### Q6: (Tutorial) Replicate

Write a function that takes an element `x`

and a
non-negative integer `n`

, and returns a list with `x`

repeated `n`

times.

Run in 61A Code

Tip:If you aren't sure where to start, try writing the corresponding recursive function for Linked Lists in Python first!

```
scm> (replicate 5 3)
(5 5 5)
```

### Q7: (Tutorial) Run Length Encoding

A**run-length encoding**is a method of compressing a sequence of letters. The list

`(a a a b a a a a)`

can be compressed to ```
((a
3) (b 1) (a 4))
```

, where the compressed version of the sequence keeps track of
how many letters appear consecutively.
Write a function that takes a compressed sequence and expands it into the original sequence.

Hint:You may want to use`my-append`

and`replicate`

.

`my-append`

is implemented as follows, where `my-append`

takes in two lists and concatenates them together.

```
(define (my-append a b)
(if (null? a)
b
(cons (car a) (my-append (cdr a) b))))
```

```
scm> (my-append '(1 2 3) '(2 3 4))
(1 2 3 2 3 4)
```

Run in 61A Code
```
scm> (uncompress '((a 1) (b 2) (c 3)))
(a b b c c c)
```

### Q8: (Tutorial) Map

Write a function that takes a procedure and applies it to every element in a given list. Run in 61A Code```
scm> (map (lambda (x) (* x x)) '(1 2 3))
(1 4 9)
```

### Q9: (Tutorial) Make Tree

Fill in the following to complete an abstract tree data type:

Run in 61A Code### Q10: (Tutorial) Tree Sum

Using the abstract data type above, write a function that sums up the entries of a tree, assuming that the entries are all numbers.Run in 61A Code

Hint:you may want to use the`map`

function you defined above, and also write a helper function for summing up the entries of a list.
