Discussion 11: Interpreters

This is an online worksheet that you can work on during discussions and tutorials. Your work is not graded and you do not need to submit anything.

Discussion 11 Vitamin

To encourage everyone to watch or attend discussion orientation, we have created small discussion vitamins. If you complete 5 of the 6 vitamins, you can earn one point of extra credit added to your final grade in the course. Please answer all of the questions in this form by Thursday at 11:59 PM.

Calculator

An interpreter is a program that understands other programs. Today, we will explore how to build an interpreter for Calculator, a simple language that uses a subset of Scheme syntax.

The Calculator language includes only the four basic arithmetic operations: +, -, *, and /. These operations can be nested and can take any numbers of arguments. A few examples of calculator expressions and their corresponding values are shown below.

calc> (+ 2 2)
4

calc> (- 5)
-5

calc> (* (+ 1 2) (+ 2 3))
15

The reader component of an interpreter parses input strings and represents them as data structures in the implementing language. In this case, we need to represent Calculator expressions as Python objects. To represent numbers, we can just use Python numbers. To represent the names of the arithmetic procedures, we can use Python strings (e.g. '+').

Call expressions are a bit more complicated. Like Scheme call expressions, Calculator call expressions look just like Scheme lists. For example, to construct the expression (+ 2 3) in Scheme, we would do the following:

scm> (cons '+ (cons 2 (cons 3 nil)))
(+ 2 3)

To represent Scheme lists in Python, we will use the Pair class. A Pair instance holds exactly two elements. Accordingly, the Pair constructor takes in two arguments, and to make a list we must nest calls to the constructor and pass in nil as the second element of the last pair. Note that in our implementation, nil is bound to a special user-defined object that represents an empty list, whereas nil in Scheme is actually an empty list.

>>> Pair('+', Pair(2, Pair(3, nil)))
Pair('+', Pair(2, Pair(3, nil)))

Each Pair instance has two instance attributes: first and rest, which are bound to the first and second elements of the pair respectively.

>>> p = Pair('+', Pair(2, Pair(3, nil)))
>>> p.first
'+'
>>> p.rest
Pair(2, Pair(3, nil))
>>> p.rest.first
2

Pair is very similar to Link, the class we developed for representing linked lists -- they have the same attribute names first and rest and are represented very similarly. Here's an implementation of what we described:

class Pair:
    """Represents the built-in pair data structure in Scheme."""
    def __init__(self, first, rest):
        self.first = first
        if not scheme_valid_cdrp(rest):
            raise SchemeError("cdr can only be a pair, nil, or a promise but was {}".format(rest))
        self.rest = rest

    def map(self, fn):
        """Maps fn to every element in a list, returning a new
        Pair.

        >>> Pair(1, Pair(2, Pair(3, nil))).map(lambda x: x * x)
        Pair(1, Pair(4, Pair(9, nil)))
        """
        assert isinstance(self.rest, Pair) or self.rest is nil, \
            "rest element in pair must be another pair or nil"
        return Pair(fn(self.first), self.rest.map(fn))

    def __repr__(self):
        return 'Pair({}, {})'.format(self.first, self.rest)
class nil:
    """Represents the special empty pair nil in Scheme."""
    def map(self, fn):
        return nil
    def __getitem__(self, i):
        raise IndexError('Index out of range')
    def __repr__(self):
        return 'nil'

nil = nil() # this hides the nil class *forever*

Questions

Q1: From Pair to Calculator

Write out the Calculator expression with proper syntax that corresponds to the following Pair constructor calls. Also, draw out a box and pointer diagram corresponding to each input.

>>> Pair('+', Pair(1, Pair(2, Pair(3, Pair(4, nil)))))

> (+ 1 2 3 4)

>>> Pair('+', Pair(1, Pair(Pair('*', Pair(2, Pair(3, nil))), nil)))

> (+ 1 (* 2 3))

Q2: Using Pair

Answer the following questions about a Pair instance representing the Calculator expression (+ (- 2 4) 6 8).

Write out the Python expression that returns a Pair representing the given expression:

>>> Pair('+', Pair(Pair('-', Pair(2, Pair(4, nil))), Pair(6, Pair(8, nil))))

Draw a box and pointer diagram corresponding to the Pair:

.
.
.
.

What is the operator of the call expression?

+

If the Pair you constructed in the previous part was bound to the name p, how would you retrieve the operator?

p.first

What are the operands of the call expression?

An expression (- 2 4), the number 6, the number 8.

If the Pair you constructed was bound to the name p, how would you retrieve a list containing all of the operands?

p.rest

How would you retrieve only the first operand?

p.rest.first

Evaluation

The evaluation component of an interpreter determines the type of an expression and executes corresponding evaluation rules.

Here are the evaluation rules for the three types of Calculator expressions:

  1. Numbers are self-evaluating, and can be thought of as primitives. For example, the numbers 3.14 and 165 just evaluate to themselves.
  2. Names are looked up in the OPERATORS dictionary. In this dictionary, each name (e.g. '+') is bound to a corresponding function in Python that does the appropriate operation on a list of numbers (e.g. sum).
  3. Call expressions are evaluated the same way you've been doing them all semester:

    1. Evaluate the operator, which evaluates to a function.
    2. Evaluate the operands from left to right.
    3. Apply the function to the value of the operands.

The function calc_eval takes in a Calculator expression represented in Python and implements each of these rules:

def calc_eval(exp):
    """Evaluates a Calculator expression represented as a Pair."""
    if isinstance(exp, Pair): # Call expressions
        fn = calc_eval(exp.first)
        args = list(exp.rest.map(calc_eval))
        return calc_apply(fn, args)
    elif exp in OPERATORS:    # Names
        return OPERATORS[exp]
    else:                     # Numbers
        return exp

calc_eval is recursive! In order to evaluate call expressions, we must call calc_eval on the operator and each of the operands.

The apply step in the Calculator language is straight-forward since we only have primitive procedures. This step will be more complex in the Scheme project since the procedures may include user-defined procedures.

Given the Python function that implements the appropriate Calculator operation and a Python list of numbers, the calc_apply function simply calls the function on the arguments, and regular Python evaluation rules take place.

def calc_apply(fn, args):
    """Applies a Calculator operation to a list of numbers."""
    return fn(args)

Questions

Q3: Counting Eval and Apply

How many calls to calc_eval and calc_apply would it take to evaluate each of the following Calculator expressions?

> (+ 2 4 6 8)

6 calls to eval: 1 for the entire expression, and then 1 each for the operator and each operand.

1 call to apply the addition operator.

> (+ 2 (* 4 (- 6 8)))

10 calls to eval: 1 for the whole expression, then 1 for each of the operators and operands. When we encounter another call expression, we have to evaluate the operators and operands inside as well.

3 calls to apply the function to the arguments for each call expression.

Video Walkthrough

Q4: New Operators

Suppose we want to add handling for comparison operators >, <, and = as well as and expressions to our Calculator interpreter. These should work the same way they do in Scheme.

calc> (and (= 1 1) 3)
3
calc> (and (+ 1 0) (< 1 0) (/ 1 0))
#f

i. Are we able to handle expressions containing the comparison operators (such as <, >, or =) with the existing implementation of calc_eval? Why or why not?

Comparison expressions are regular call expressions, so we need to evaluate the operator and operands and then apply a function to the arguments. Therefore, we do not need to change calc_eval. We simply need to add new entries to the OPERATORS dictionary that map '<', '>', and '=' to functions that perform the appropriate comparison operation.

ii. Are we able to handle and expressions with the existing implementation of calc_eval? Why or why not?

Hint: Think about the rules of evaluation we've implemented in calc_eval. Is anything different about and?

Since and is a special form that short circuits on the first false-y operand, we cannot handle these expressions the same way we handle call expressions. We need to add special handling for combinations that don't evaluate all the operands.

iii. Now, complete the implementation below to handle and expressions. You may assume the conditional operators (e.g. <, >, =, etc) have already been implemented for you.

Your Answer
Run in 61A Code
Solution
def calc_eval(exp):
    if isinstance(exp, Pair):
if exp.first == 'and': # and expressions
return eval_and(exp.rest) else: # Call expressions return calc_apply(calc_eval(exp.first), list(exp.rest.map(calc_eval))) elif exp in OPERATORS: # Names return OPERATORS[exp] else: # Numbers return exp def eval_and(operands):
curr, val = operands, True while curr is not nil: val = calc_eval(curr.first) if val is False: return False curr = curr.rest return val

Interpreters Tutorial Discussions

Q5: (Tutorial) Interpreters Review

Discuss the follow questions with your tutorial group - they will be helpful for your understanding of the Scheme project! If you wish to take notes, we recommend you take notes on a separate document so it won't accidentally get erased.

What are the four parts of an interpreter (Hint: what does REPL stand for)? What does each part do? What parts did you work on implementing in the discussion?

The four parts of an interpreter are read, evaluate, print and loop.

Read takes in the user input code and outputs some data structure representing the expression.

Evaluate takes in this data structure and outputs a value representing what this expression evaluates to. In this step, call expressions, arithmetic expressions, special forms, etc. will all turn into simple values / primitives.

Print takes in however the value returned from the evaluate stage is represented and displays a human-readable form to the user interacting with the interpreter.

Loop simply means loop! We go back to the read stage to execute the next user-inputted line of code.

In this discussion, we worked on Read and Evaluate. In the scheme project you will also be implementing the Read and Evaluate stages of the Scheme Interpreter.

For the Calculator interpreter implemented in discussion, for the following executed code, what would be the input into the "Read" portion of the interpreter?

calc> (+ 2 3)
5
(+ 2 3)

What would be the output of the "Read" portion for the same code?

Pair('+', Pair(2, Pair(3, nil)))

How does the evaluate stage work in Calculator? How do we know if an input into calc_eval is a call expression?

In the evaluate stage, Pairs are inputted and passed into calc_eval to be turned into values. We know the input is a call expression if it is a Pair. If it's an operator (such as +, -, etc), we return the corresponding operator. Else, we know it's a primitive, and so we return itself, since primitives evaluate to themselves.

Very importantly, the evaluate stage is recursive -- in particular, remember the rules of evaluation:

  1. Evaluate the operator, which evaluates to a function.
  2. Evaluate the operands from left to right.
  3. Apply the function to the value of the operands.

Steps 1 and 2 recursively evaluate the operator and operands again!

Scheme Lists

Q6: (Tutorial) Replicate

Write a function that takes an element x and a non-negative integer n, and returns a list with x repeated n times.

Tip: If you aren't sure where to start, try writing the corresponding recursive function for Linked Lists in Python first!

Your Answer
Run in 61A Code
Solution
(define (replicate x n)
(if (= n 0) nil (cons x (replicate x (- n 1))) )
) ;;; Tests (replicate 5 3) ; expect (5 5 5)
scm> (replicate 5 3)
(5 5 5)

Q7: (Tutorial) Run Length Encoding

A run-length encoding is a method of compressing a sequence of letters. The list (a a a b a a a a) can be compressed to ((a 3) (b 1) (a 4)), where the compressed version of the sequence keeps track of how many letters appear consecutively.

Write a function that takes a compressed sequence and expands it into the original sequence.

Hint: You may want to use my-append and replicate.

my-append is implemented as follows, where my-append takes in two lists and concatenates them together.

(define (my-append a b)
    (if (null? a)
    b
    (cons (car a) (my-append (cdr a) b))))
scm> (my-append '(1 2 3) '(2 3 4))
(1 2 3 2 3 4)
Your Answer
Run in 61A Code
Solution
(define (uncompress s)
(if (null? s) s (my-append (replicate (car (car s)) (car (cdr (car s)))) (uncompress (cdr s))))
) ;;; Tests (uncompress '((a 1) (b 2) (c 3))) ; expect (a b b c c c)
scm> (uncompress '((a 1) (b 2) (c 3)))
(a b b c c c)

Q8: (Tutorial) Map

Write a function that takes a procedure and applies it to every element in a given list. Your Answer
Run in 61A Code
Solution
(define (map fn lst)
(if (null? lst) nil (cons (fn (car lst)) (map fn (cdr lst))))
) ;;; Tests (map (lambda (x) (* x x)) '(1 2 3)) ; expect (1 4 9)
scm> (map (lambda (x) (* x x)) '(1 2 3))
(1 4 9)

Q9: (Tutorial) Make Tree

Fill in the following to complete an abstract tree data type:

Your Answer
Run in 61A Code
Solution
(define (make-tree label branches) (cons label branches))

(define (label tree)
(car tree)
) (define (branches tree)
(cdr tree)
)

Q10: (Tutorial) Tree Sum

Using the abstract data type above, write a function that sums up the entries of a tree, assuming that the entries are all numbers.

Hint: you may want to use the map function you defined above, and also write a helper function for summing up the entries of a list.

Your Answer
Run in 61A Code
Solution
(define (tree-sum tree)
(+ (label tree) (sum (map tree-sum (branches tree))))
)
(define (sum lst) (if (null? lst) 0 (+ (car lst) (sum (cdr lst)))))
