Lab 9 Solutions

Solution Files

Topics

Consult this section if you need a refresher on the material for this lab. It's okay to skip directly to the questions and refer back here should you get stuck.

Linked Lists

We've learned that a Python list is one way to store sequential values. Another type of list is a linked list. A Python list stores all of its elements in a single object, and each element can be accessed by using its index. A linked list, on the other hand, is a recursive object that only stores two things: its first value and a reference to the rest of the list, which is another linked list.

We can implement a class, Link, that represents a linked list object. Each instance of Link has two instance attributes, first and rest.

class Link:
    """A linked list.

    >>> s = Link(1)
    >>> s.first
    1
    >>> s.rest is Link.empty
    True
    >>> s = Link(2, Link(3, Link(4)))
    >>> s.first = 5
    >>> s.rest.first = 6
    >>> s.rest.rest = Link.empty
    >>> s                                    # Displays the contents of repr(s)
    Link(5, Link(6))
    >>> s.rest = Link(7, Link(Link(8, Link(9))))
    >>> s
    Link(5, Link(7, Link(Link(8, Link(9)))))
    >>> print(s)                             # Prints str(s)
    <5 7 <8 9>>
    """
    empty = ()

    def __init__(self, first, rest=empty):
        assert rest is Link.empty or isinstance(rest, Link)
        self.first = first
        self.rest = rest

    def __repr__(self):
        if self.rest is not Link.empty:
            rest_repr = ', ' + repr(self.rest)
        else:
            rest_repr = ''
        return 'Link(' + repr(self.first) + rest_repr + ')'

    def __str__(self):
        string = '<'
        while self.rest is not Link.empty:
            string += str(self.first) + ' '
            self = self.rest
        return string + str(self.first) + '>'

A valid linked list can be one of the following:

  1. An empty linked list (Link.empty)
  2. A Link object containing the first value of the linked list and a reference to the rest of the linked list

What makes a linked list recursive is that the rest attribute of a single Link instance is another linked list! In the big picture, each Link instance stores a single value of the list. When multiple Links are linked together through each instance's rest attribute, an entire sequence is formed.

Note: This definition means that the rest attribute of any Link instance must be either Link.empty or another Link instance! This is enforced in Link.__init__, which raises an AssertionError if the value passed in for rest is neither of these things.

To check if a linked list is empty, compare it against the class attribute Link.empty. For example, the function below prints out whether or not the link it is handed is empty:

def test_empty(link):
    if link is Link.empty:
        print('This linked list is empty!')
    else:
        print('This linked list is not empty!')

Motivation: Why linked lists

Since you are already familiar with Python's built-in lists, you might be wondering why we are teaching you another list representation. There are historical reasons, along with practical reasons. Later in the course, you'll be programming in Scheme, which is a programming language that uses linked lists for almost everything.

For now, let's compare linked lists and Python lists by looking at two common sequence operations: inserting an item and indexing.

Python's built-in list is like a sequence of containers with indices on them:

arraylist

Linked lists are a list of items pointing to their neighbors. Notice that there's no explicit index for each item.

linkedlist

Suppose we want to add an item at the head of the list.

  • With Python's built-in list, if you want to put an item into the container labeled with index 0, you must move all the items in the list into its neighbor containers to make room for the first item;

arraylist

  • With a linked list, you tell Python that the neighbor of the new item is the old beginning of the list.

arraylist

Now, let's take a look at indexing. Say we want the item at index 3 from a list.

  • In the built-in list, you can use Python list indexing, e.g. lst[3], to easily get the item at index 3.
  • In the linked list, you need to start at the first item and repeatedly follow the rest attribute, e.g. link.rest.rest.first. How does this scale if the index you were trying to access was very large?

Can you think of situations where you would want to use one type of list over another? In this class, we aren't too worried about performance. However, in future computer science courses, you'll learn how to make performance tradeoffs in your programs by choosing your data structures carefully.


Mutable Trees

Recall that a tree is a recursive abstract data type that has a label (the value stored in the root of the tree) and branches (a list of trees directly underneath the root).

We saw one way to implement the tree ADT -- using constructor and selector functions that treat trees as lists. Another, more formal, way to implement the tree ADT is with a class. Here is part of the class definition for Tree, which can be found in lab07.py:

class Tree:
    """
    >>> t = Tree(3, [Tree(2, [Tree(5)]), Tree(4)])
    >>> t.label
    3
    >>> t.branches[0].label
    2
    >>> t.branches[1].is_leaf()
    True
    """
    def __init__(self, label, branches=[]):
        for b in branches:
            assert isinstance(b, Tree)
        self.label = label
        self.branches = list(branches)

    def is_leaf(self):
        return not self.branches

Even though this is a new implementation, everything we know about the tree ADT remains true. That means that solving problems involving trees as objects uses the same techniques that we developed when first studying the tree ADT (e.g. we can still use recursion on the branches!). The main difference, aside from syntax, is that tree objects are mutable.

Here is a summary of the differences between the tree ADT implemented using functions and lists vs. implemented using a class:

- Tree constructor and selector functions Tree class
Constructing a tree To construct a tree given a label and a list of branches, we call tree(label, branches) To construct a tree object given a label and a list of branches, we call Tree(label, branches) (which calls the Tree.__init__ method)
Label and branches To get the label or branches of a tree t, we call label(t) or branches(t) respectively To get the label or branches of a tree t, we access the instance attributes t.label or t.branches respectively
Mutability The tree ADT is immutable because we cannot assign values to call expressions The label and branches attributes of a Tree instance can be reassigned, mutating the tree
Checking if a tree is a leaf To check whether a tree t is a leaf, we call the convenience function is_leaf(t) To check whether a tree t is a leaf, we call the bound method t.is_leaf(). This method can only be called on Tree objects.

Required Questions

Linked Lists

Q1: WWPD: Linked Lists

Read over the Link class in lab09.py. Make sure you understand the doctests.

Use Ok to test your knowledge with the following "What Would Python Display?" questions:

python3 ok -q link -u

Enter Function if you believe the answer is <function ...>, Error if it errors, and Nothing if nothing is displayed.

If you get stuck, try drawing out the box-and-pointer diagram for the linked list on a piece of paper or loading the Link class into the interpreter with python3 -i lab09.py.

>>> from lab07 import *
>>> link = Link(1000)
>>> link.first
______
1000
>>> link.rest is Link.empty
______
True
>>> link = Link(1000, 2000)
______
AssertionError
>>> link = Link(1000, Link())
______
TypeError
>>> from lab07 import *
>>> link = Link(1, Link(2, Link(3)))
>>> link.first
______
1
>>> link.rest.first
______
2
>>> link.rest.rest.rest is Link.empty
______
True
>>> link.first = 9001 >>> link.first
______
9001
>>> link.rest = link.rest.rest >>> link.rest.first
______
3
>>> link = Link(1) >>> link.rest = link >>> link.rest.rest.rest.rest.first
______
1
>>> link = Link(2, Link(3, Link(4))) >>> link2 = Link(1, link) >>> link2.first
______
1
>>> link2.rest.first
______
2
>>> from lab07 import *
>>> link = Link(5, Link(6, Link(7)))
>>> link                  # Look at the __repr__ method of Link
______
Link(5, Link(6, Link(7)))
>>> print(link) # Look at the __str__ method of Link
______
<5 6 7>

Q2: Convert Link

Write a function convert_link that takes in a linked list and returns the sequence as a Python list. You may assume that the input list is shallow; none of the elements is another linked list.

Try to find both an iterative and recursive solution for this problem!

def convert_link(link):
    """Takes a linked list and returns a Python list with the same elements.

    >>> link = Link(1, Link(2, Link(3, Link(4))))
    >>> convert_link(link)
    [1, 2, 3, 4]
    >>> convert_link(Link.empty)
    []
    """
# Recursive solution if link is Link.empty: return [] return [link.first] + convert_link(link.rest) # Iterative solution def convert_link_iterative(link): result = [] while link is not Link.empty: result.append(link.first) link = link.rest return result

Use Ok to test your code:

python3 ok -q convert_link
Walkthrough:

Q3: Every Other

Implement every_other, which takes a linked list s. It mutates s such that all of the odd-indexed elements (using 0-based indexing) are removed from the list. For example:

>>> s = Link('a', Link('b', Link('c', Link('d'))))
>>> every_other(s)
>>> s.first
'a'
>>> s.rest.first
'c'
>>> s.rest.rest is Link.empty
True

If s contains fewer than two elements, s remains unchanged.

Do not return anything! every_other should mutate the original list.

def every_other(s):
    """Mutates a linked list so that all the odd-indiced elements are removed
    (using 0-based indexing).

    >>> s = Link(1, Link(2, Link(3, Link(4))))
    >>> every_other(s)
    >>> s
    Link(1, Link(3))
    >>> odd_length = Link(5, Link(3, Link(1)))
    >>> every_other(odd_length)
    >>> odd_length
    Link(5, Link(1))
    >>> singleton = Link(4)
    >>> every_other(singleton)
    >>> singleton
    Link(4)
    """
if s is Link.empty or s.rest is Link.empty: return else: s.rest = s.rest.rest every_other(s.rest)

Use Ok to test your code:

python3 ok -q every_other

Mutable Trees

Q4: Square

Write a function label_squarer that mutates a Tree with numerical labels so that each label is squared.

def label_squarer(t):
    """Mutates a Tree t by squaring all its elements.

    >>> t = Tree(1, [Tree(3, [Tree(5)]), Tree(7)])
    >>> label_squarer(t)
    >>> t
    Tree(1, [Tree(9, [Tree(25)]), Tree(49)])
    """
t.label = t.label ** 2 for subtree in t.branches: label_squarer(subtree)

Use Ok to test your code:

python3 ok -q label_squarer

Q5: Cumulative Mul

Write a function cumulative_mul that mutates the Tree t so that each node's label becomes the product of all labels in the subtree rooted at the node.

def cumulative_mul(t):
    """Mutates t so that each node's label becomes the product of all labels in
    the corresponding subtree rooted at t.

    >>> t = Tree(1, [Tree(3, [Tree(5)]), Tree(7)])
    >>> cumulative_mul(t)
    >>> t
    Tree(105, [Tree(15, [Tree(5)]), Tree(7)])
    """
for b in t.branches: cumulative_mul(b) total = t.label for b in t.branches: total *= b.label t.label = total

Use Ok to test your code:

python3 ok -q cumulative_mul

Optional Questions

Q6: Cycles

The Link class can represent lists with cycles. That is, a list may contain itself as a sublist.

>>> s = Link(1, Link(2, Link(3)))
>>> s.rest.rest.rest = s
>>> s.rest.rest.rest.rest.rest.first
3

Implement has_cycle,that returns whether its argument, a Link instance, contains a cycle.

Hint: Iterate through the linked list and try keeping track of which Link objects you've already seen.

def has_cycle(link):
    """Return whether link contains a cycle.

    >>> s = Link(1, Link(2, Link(3)))
    >>> s.rest.rest.rest = s
    >>> has_cycle(s)
    True
    >>> t = Link(1, Link(2, Link(3)))
    >>> has_cycle(t)
    False
    >>> u = Link(2, Link(2, Link(2)))
    >>> has_cycle(u)
    False
    """
links = [] while link is not Link.empty: if link in links: return True links.append(link) link = link.rest return False

Use Ok to test your code:

python3 ok -q has_cycle

As an extra challenge, implement has_cycle_constant with only constant space. (If you followed the hint above, you will use linear space.) The solution is short (less than 20 lines of code), but requires a clever idea. Try to discover the solution yourself before asking around:

def has_cycle_constant(link):
    """Return whether link contains a cycle.

    >>> s = Link(1, Link(2, Link(3)))
    >>> s.rest.rest.rest = s
    >>> has_cycle_constant(s)
    True
    >>> t = Link(1, Link(2, Link(3)))
    >>> has_cycle_constant(t)
    False
    """
if link is Link.empty: return False slow, fast = link, link.rest while fast is not Link.empty: if fast.rest == Link.empty: return False elif fast is slow or fast.rest is slow: return True else: slow, fast = slow.rest, fast.rest.rest return False

Use Ok to test your code:

python3 ok -q has_cycle_constant

Q7: Reverse Other

Write a function reverse_other that mutates the tree such that labels on every other (odd-depth) level are reversed. For example, Tree(1,[Tree(2, [Tree(4)]), Tree(3)]) becomes Tree(1,[Tree(3, [Tree(4)]), Tree(2)]). Notice that the nodes themselves are not reversed; only the labels are.

def reverse_other(t):
    """Mutates the tree such that nodes on every other (odd-depth) level
    have the labels of their branches all reversed.

    >>> t = Tree(1, [Tree(2), Tree(3), Tree(4)])
    >>> reverse_other(t)
    >>> t
    Tree(1, [Tree(4), Tree(3), Tree(2)])
    >>> t = Tree(1, [Tree(2, [Tree(3, [Tree(4), Tree(5)]), Tree(6, [Tree(7)])]), Tree(8)])
    >>> reverse_other(t)
    >>> t
    Tree(1, [Tree(8, [Tree(3, [Tree(5), Tree(4)]), Tree(6, [Tree(7)])]), Tree(2)])
    """
def reverse_helper(t, need_reverse): if t.is_leaf(): return new_labs = [child.label for child in t.branches][::-1] for i in range(len(t.branches)): child = t.branches[i] reverse_helper(child, not need_reverse) if need_reverse: child.label = new_labs[i] reverse_helper(t, True)

Use Ok to test your code:

python3 ok -q reverse_other
