Lab 12 Solutions

Solution Files

Note

Note: We will be releasing lab solutions Wednesday morning (pre-deadline)! You still have to turn in the lab to get credit, however. (It's fine to copy/paste the staff solution once it's released, if you don't have time, but please try to read over the solutions if you do this.)

Review Topics

Tree Recursion

A tree recursive function is a recursive function that makes more than one call to itself, resulting in a tree-like series of calls.

A classic example of a tree recursion function is finding the nth Fibonacci number:

def fib(n):
    if n == 0 or n == 1:
        return n
    return fib(n - 1) + fib(n - 2)

Calling fib(6) results in the following call structure (where f is fib):

Fibonacci Tree

Each f(i) node represents a recursive call to fib. Each recursive call makes another two recursive calls. f(0) and f(1) do not make any recursive calls because they are the base cases of the function. Because of these base cases, we are able to terminate the recursion and beginning accumulating the values.

Generally, tree recursion is effective when you want to explore multiple possibilities or choices at a single step. In these types of problems, you make a recursive call for each choice or for a group of choices. Here are some examples:

  • Given a list of paid tasks and a limited amount of time, which tasks should you choose to maximize your pay? This is actually a variation of the Knapsack problem, which focuses on finding some optimal combination of different items.
  • Suppose you are lost in a maze and see several different paths. How do you find your way out? This is an example of path finding, and is tree recursive because at every step, you could have multiple directions to choose from that could lead out of the maze.
  • Your dryer costs $2 per cycle and accepts all types of coins. How many different combinations of coins can you create to run the dryer? This is similar to the partitions problem from the textbook.

Trees

Recall that a tree is a recursive abstract data type that has a label (the value stored in the root of the tree) and branches (a list of trees directly underneath the root).

We saw one way to implement the tree ADT -- using constructor and selector functions that treat trees as lists. Another, more formal, way to implement the tree ADT is with a class. Here is part of the class definition for Tree, which can be found in lab07.py:

class Tree:
    """
    >>> t = Tree(3, [Tree(2, [Tree(5)]), Tree(4)])
    >>> t.label
    3
    >>> t.branches[0].label
    2
    >>> t.branches[1].is_leaf()
    True
    """
    def __init__(self, label, branches=[]):
        for b in branches:
            assert isinstance(b, Tree)
        self.label = label
        self.branches = list(branches)

    def is_leaf(self):
        return not self.branches

Even though this is a new implementation, everything we know about the tree ADT remains true. That means that solving problems involving trees as objects uses the same techniques that we developed when first studying the tree ADT (e.g. we can still use recursion on the branches!). The main difference, aside from syntax, is that tree objects are mutable.

Here is a summary of the differences between the tree ADT implemented using functions and lists vs. implemented using a class:

- Tree constructor and selector functions Tree class
Constructing a tree To construct a tree given a label and a list of branches, we call tree(label, branches) To construct a tree object given a label and a list of branches, we call Tree(label, branches) (which calls the Tree.__init__ method)
Label and branches To get the label or branches of a tree t, we call label(t) or branches(t) respectively To get the label or branches of a tree t, we access the instance attributes t.label or t.branches respectively
Mutability The tree ADT is immutable because we cannot assign values to call expressions The label and branches attributes of a Tree instance can be reassigned, mutating the tree
Checking if a tree is a leaf To check whether a tree t is a leaf, we call the convenience function is_leaf(t) To check whether a tree t is a leaf, we call the bound method t.is_leaf(). This method can only be called on Tree objects.

Linked Lists

We've learned that a Python list is one way to store sequential values. Another type of list is a linked list. A Python list stores all of its elements in a single object, and each element can be accessed by using its index. A linked list, on the other hand, is a recursive object that only stores two things: its first value and a reference to the rest of the list, which is another linked list.

We can implement a class, Link, that represents a linked list object. Each instance of Link has two instance attributes, first and rest.

class Link:
    """A linked list.

    >>> s = Link(1)
    >>> s.first
    1
    >>> s.rest is Link.empty
    True
    >>> s = Link(2, Link(3, Link(4)))
    >>> s.first = 5
    >>> s.rest.first = 6
    >>> s.rest.rest = Link.empty
    >>> s                                    # Displays the contents of repr(s)
    Link(5, Link(6))
    >>> s.rest = Link(7, Link(Link(8, Link(9))))
    >>> s
    Link(5, Link(7, Link(Link(8, Link(9)))))
    >>> print(s)                             # Prints str(s)
    <5 7 <8 9>>
    """
    empty = ()

    def __init__(self, first, rest=empty):
        assert rest is Link.empty or isinstance(rest, Link)
        self.first = first
        self.rest = rest

    def __repr__(self):
        if self.rest is not Link.empty:
            rest_repr = ', ' + repr(self.rest)
        else:
            rest_repr = ''
        return 'Link(' + repr(self.first) + rest_repr + ')'

    def __str__(self):
        string = '<'
        while self.rest is not Link.empty:
            string += str(self.first) + ' '
            self = self.rest
        return string + str(self.first) + '>'

A valid linked list can be one of the following:

  1. An empty linked list (Link.empty)
  2. A Link object containing the first value of the linked list and a reference to the rest of the linked list

What makes a linked list recursive is that the rest attribute of a single Link instance is another linked list! In the big picture, each Link instance stores a single value of the list. When multiple Links are linked together through each instance's rest attribute, an entire sequence is formed.

Note: This definition means that the rest attribute of any Link instance must be either Link.empty or another Link instance! This is enforced in Link.__init__, which raises an AssertionError if the value passed in for rest is neither of these things.

To check if a linked list is empty, compare it against the class attribute Link.empty. For example, the function below prints out whether or not the link it is handed is empty:

def test_empty(link):
    if link is Link.empty:
        print('This linked list is empty!')
    else:
        print('This linked list is not empty!')

OOP

Object-oriented programming (OOP) is a style of programming that allows you to think of code in terms of "objects." Here's an example of a Car class:

class Car(object):
    num_wheels = 4

    def __init__(self, color):
        self.wheels = Car.num_wheels
        self.color = color

    def drive(self):
        if self.wheels <= Car.num_wheels:
            return self.color + ' car cannot drive!'
        return self.color + ' car goes vroom!'

    def pop_tire(self):
        if self.wheels > 0:
            self.wheels -= 1

Here's some terminology:

  • class: a blueprint for how to build a certain type of object. The Car class (shown above) describes the behavior and data that all Car objects have.
  • instance: a particular occurrence of a class. In Python, we create instances of a class like this:

    >>> my_car = Car('red')

    my_car is an instance of the Car class.

  • attribute or field: a variable that belongs to the class. Think of an attribute as a quality of the object: cars have wheels and color, so we have given our Car class self.wheels and self.color attributes. We can access attributes using dot notation:

    >>> my_car.color
    'red'
    >>> my_car.wheels
    4
  • method: Methods are just like normal functions, except that they are tied to an instance or a class. Think of a method as a "verb" of the class: cars can drive and also pop their tires, so we have given our Car class the methods drive and pop_tire. We call methods using dot notation:

    >>> my_car = Car('red')
    >>> my_car.drive()
    'red car goes vroom!'
  • constructor: As with data abstraction, constructors describe how to build an instance of the class. Most classes have a constructor. In Python, the constructor of the class defined as __init__. For example, here is the Car class's constructor:

    def __init__(self, color):
        self.wheels = Car.num_wheels
        self.color = color

    The constructor takes in one argument, color. As you can see, the constructor also creates the self.wheels and self.color attributes.

  • self: in Python, self is the first parameter for many methods (in this class, we will only use methods whose first parameter is self). When a method is called, self is bound to an instance of the class. For example:

    >>> my_car = Car('red')
    >>> car.drive()

    Notice that the drive method takes in self as an argument, but it looks like we didn't pass one in! This is because the dot notation implicitly passes in car as self for us.

Required Questions

Trees

Q1: Prune Min

Write a function that prunes a Tree t mutatively. t and its branches always have zero or two branches. For the trees with two branches, reduce the number of branches from two to one by keeping the branch that has the smaller label value. Do nothing with trees with zero branches.

Prune the tree from the bottom up. The result should be a linear tree.

def prune_min(t):
    """Prune the tree mutatively from the bottom up.

    >>> t1 = Tree(6)
    >>> prune_min(t1)
    >>> t1
    Tree(6)
    >>> t2 = Tree(6, [Tree(3), Tree(4)])
    >>> prune_min(t2)
    >>> t2
    Tree(6, [Tree(3)])
    >>> t3 = Tree(6, [Tree(3, [Tree(1), Tree(2)]), Tree(5, [Tree(3), Tree(4)])])
    >>> prune_min(t3)
    >>> t3
    Tree(6, [Tree(3, [Tree(1)])])
    """
if t.branches == []: return prune_min(t.branches[0]) prune_min(t.branches[1]) if (t.branches[0].label > t.branches[1].label): t.branches.pop(0) else: t.branches.pop(1)

Use Ok to test your code:

python3 ok -q prune_min

Q2: Remainder Generator

Like functions, generators can also be higher-order. For this problem, we will be writing remainders_generator, which yields a series of generator objects.

remainders_generator takes in an integer m, and yields m different generators. The first generator is a generator of multiples of m, i.e. numbers where the remainder is 0. The second is a generator of natural numbers with remainder 1 when divided by m. The last generator yields natural numbers with remainder m - 1 when divided by m.

Hint: You can call the naturals function to create a generator of infinite natural numbers.

Hint: Consider defining an inner generator function. Each yielded generator varies only in that the elements of each generator have a particular remainder when divided by m. What does that tell you about the argument(s) that the inner function should take in?

def remainders_generator(m):
    """
    Yields m generators. The ith yielded generator yields natural numbers whose
    remainder is i when divided by m.

    >>> import types
    >>> [isinstance(gen, types.GeneratorType) for gen in remainders_generator(5)]
    [True, True, True, True, True]
    >>> remainders_four = remainders_generator(4)
    >>> for i in range(4):
    ...     print("First 3 natural numbers with remainder {0} when divided by 4:".format(i))
    ...     gen = next(remainders_four)
    ...     for _ in range(3):
    ...         print(next(gen))
    First 3 natural numbers with remainder 0 when divided by 4:
    4
    8
    12
    First 3 natural numbers with remainder 1 when divided by 4:
    1
    5
    9
    First 3 natural numbers with remainder 2 when divided by 4:
    2
    6
    10
    First 3 natural numbers with remainder 3 when divided by 4:
    3
    7
    11
    """
def gen(i): for e in naturals(): if e % m == i: yield e for i in range(m): yield gen(i)

Note that if you have implemented this correctly, each of the generators yielded by remainder_generator will be infinite - you can keep calling next on them forever without running into a StopIteration exception.

Use Ok to test your code:

python3 ok -q remainders_generator

Folding Linked Lists

When we write recursive functions acting on Links, we often find that they have the following form:

def func(link):
    if link is Link.empty:
        return <Base case>
    else:
        return <Expression involving func(link.rest)>

In the spirit of abstraction, we want to factor out this commonly seen pattern. It turns out that we can define an abstraction called fold that do this.

A linked list can be represented as a series of Link constructors, where Link.rest is either another linked list or the empty list.

We represent such a list in the diagram below:

Right fold

In this diagram, the recursive list

Link(1, Link(2, Link(3, Link(4,Link(5)))))

is represented with : as the constructor and [] as the empty list.

We define a function foldr that takes in a function f which takes two arguments, and a value z. foldr essentially replaces the Link constructor with f, and the empty list with z. It then evaluates the expression and returns the result. This is equivalent to:

f(1, f(2, f(3, f(4, f(5, z)))))

We call this operation a right fold.

Similarly we can define a left fold foldl that folds a list starting from the beginning, such that the function f will be applied this way:

f(f(f(f(f(z, 1), 2), 3), 4), 5)

Left fold

Also notice that a left fold is equivalent to Python's reduce with a starting value.

Q3: Fold Right

Now write the right fold function.

def foldr(link, fn, z):
    """ Right fold
    >>> lst = Link(3, Link(2, Link(1)))
    >>> foldr(lst, sub, 0) # (3 - (2 - (1 - 0)))
    2
    >>> foldr(lst, add, 0) # (3 + (2 + (1 + 0)))
    6
    >>> foldr(lst, mul, 1) # (3 * (2 * (1 * 1)))
    6
    """
if link is Link.empty: return z return fn(link.first, foldr(link.rest, fn, z))

Use Ok to test your code:

python3 ok -q foldr

Q4: Map With Fold

Write the mapl function, which takes in a Link lst and a function fn, and returns a new Link where every element is the function applied to every element of the original list. Use either foldl or foldr. Hint: it is much easier to write with one of them than the other!

def mapl(lst, fn):
    """ Maps FN on LST
    >>> lst = Link(3, Link(2, Link(1)))
    >>> mapl(lst, lambda x: x*x)
    Link(9, Link(4, Link(1)))
    """
return foldr(lst, lambda x, xs: Link(fn(x), xs), Link.empty)

Use Ok to test your code:

python3 ok -q mapl

Scheme

Q5: Compose All

Implement compose-all, which takes a list of one-argument functions and returns a one-argument function that applies each function in that list in turn to its argument. For example, if func is the result of calling compose-all on a list of functions (f g h), then (func x) should be equivalent to the result of calling (h (g (f x))).

scm> (define (square x) (* x x))
square
scm> (define (add-one x) (+ x 1))
add-one
scm> (define (double x) (* x 2))
double
scm> (define composed (compose-all (list double square add-one)))
composed
scm> (composed 1)
5
scm> (composed 2)
17
(define (compose-all funcs)
(lambda (x) (if (null? funcs) x ((compose-all (cdr funcs)) ((car funcs) x))))
)

Use Ok to test your code:

python3 ok -q compose-all

Submit

Make sure to submit this assignment by running:

python3 ok --submit

Optional Questions

Objects

Q6: Checking account

We'd like to be able to cash checks, so let's add a deposit_check method to our CheckingAccount class. It will take a Check object as an argument, and check to see if the payable_to attribute matches the CheckingAccount's holder. If so, it marks the Check as deposited, and adds the amount specified to the CheckingAccount's total.

Write an appropriate Check class, and add the deposit_check method to the CheckingAccount class. Make sure not to copy and paste code! Use inheritance whenever possible.

See the doctests for examples of how this code should work.

class CheckingAccount(Account):
    """A bank account that charges for withdrawals.

    >>> check = Check("Steven", 42)  # 42 dollars, payable to Steven
    >>> steven_account = CheckingAccount("Steven")
    >>> eric_account = CheckingAccount("Eric")
    >>> eric_account.deposit_check(check)  # trying to steal steven's money
    The police have been notified.
    >>> eric_account.balance
    0
    >>> check.deposited
    False
    >>> steven_account.balance
    0
    >>> steven_account.deposit_check(check)
    42
    >>> check.deposited
    True
    >>> steven_account.deposit_check(check)  # can't cash check twice
    The police have been notified.
    """
    withdraw_fee = 1
    interest = 0.01

    def withdraw(self, amount):
        return Account.withdraw(self, amount + self.withdraw_fee)

def deposit_check(self, check): if check.payable_to != self.holder or check.deposited: print("The police have been notified.") else: self.deposit(check.amount) check.deposited = True return self.balance
class Check(object):
def __init__(self, payable_to, amount): self.payable_to = payable_to self.amount = amount self.deposited = False

Use Ok to test your code:

python3 ok -q CheckingAccount

Linked Lists

Q7: Fold Left

Write the left fold function by filling in the blanks.

def foldl(link, fn, z):
    """ Left fold
    >>> lst = Link(3, Link(2, Link(1)))
    >>> foldl(lst, sub, 0) # (((0 - 3) - 2) - 1)
    -6
    >>> foldl(lst, add, 0) # (((0 + 3) + 2) + 1)
    6
    >>> foldl(lst, mul, 1) # (((1 * 3) * 2) * 1)
    6
    """
    if link is Link.empty:
        return z
return foldl(link.rest, fn, fn(z, link.first))

Use Ok to test your code:

python3 ok -q foldl

Q8: Filter With Fold

Write the filterl function, using either foldl or foldr.

def filterl(lst, pred):
    """ Filters LST based on PRED
    >>> lst = Link(4, Link(3, Link(2, Link(1))))
    >>> filterl(lst, lambda x: x % 2 == 0)
    Link(4, Link(2))
    """
def filtered(x, xs): if pred(x): return Link(x, xs) return xs return foldr(lst, filtered, Link.empty)

Use Ok to test your code:

python3 ok -q filterl

Q9: Reverse With Fold

Notice that mapl and filterl are not recursive anymore! We used the implementation of foldl and foldr to implement the actual recursion: we only need to provide the recursive step and the base case to fold.

Use foldl to write reverse, which takes in a recursive list and reverses it. Hint: It only takes one line!

Extra for experience: Write a version of reverse that do not use the Link constructor. You do not have to use foldl or foldr.

def reverse(lst):
    """ Reverses LST with foldl
    >>> reverse(Link(3, Link(2, Link(1))))
    Link(1, Link(2, Link(3)))
    >>> reverse(Link(1))
    Link(1)
    >>> reversed = reverse(Link.empty)
    >>> reversed is Link.empty
    True
    """
return foldl(lst, lambda x, y: Link(y, x), Link.empty) # Extra for experience def reverse2(lst): if lst is Link.empty: return lst elif lst.rest is not Link.empty: second, last = lst.rest, lst lst = reverse2(second) second.rest, last.rest = last, Link.empty return lst

Use Ok to test your code:

python3 ok -q reverse

Q10: Fold With Fold

Write foldl using foldr! You only need to fill in the step function.

identity = lambda x: x

def foldl2(link, fn, z):
    """ Write foldl using foldr
    >>> list = Link(3, Link(2, Link(1)))
    >>> foldl2(list, sub, 0) # (((0 - 3) - 2) - 1)
    -6
    >>> foldl2(list, add, 0) # (((0 + 3) + 2) + 1)
    6
    >>> foldl2(list, mul, 1) # (((1 * 3) * 2) * 1)
    6
    """
    def step(x, g):
return lambda a: g(fn(a, x))
return foldr(link, step, identity)(z)

Use Ok to test your code:

python3 ok -q foldl2

Tree Recursion

Q11: Num Splits

Given a list of numbers s and a target difference d, how many different ways are there to split s into two subsets such that the sum of the first is within d of the sum of the second? The number of elements in each subset can differ.

You may assume that the elements in s are distinct and that d is always non-negative.

Note that the order of the elements within each subset does not matter, nor does the order of the subsets themselves. For example, given the list [1, 2, 3], you should not count [1, 2], [3] and [3], [1, 2] as distinct splits.

Hint: If the number you return is too large, you may be double-counting somewhere. If the result you return is off by some constant factor, it will likely be easiest to simply divide/subtract away that factor.

def num_splits(s, d):
    """Return the number of ways in which s can be partitioned into two
    sublists that have sums within d of each other.

    >>> num_splits([1, 5, 4], 0)  # splits to [1, 4] and [5]
    1
    >>> num_splits([6, 1, 3], 1)  # no split possible
    0
    >>> num_splits([-2, 1, 3], 2) # [-2, 3], [1] and [-2, 1, 3], []
    2
    >>> num_splits([1, 4, 6, 8, 2, 9, 5], 3)
    12
    """
def difference_so_far(s, difference): if not s: if abs(difference) <= d: return 1 else: return 0 element = s[0] s = s[1:] return difference_so_far(s, difference + element) + difference_so_far(s, difference - element) return difference_so_far(s, 0)//2

Use Ok to test your code:

python3 ok -q num_splits
