Project 2: CS 61A Autocorrected Typing Software

Programmers dream of
Abstraction, recursion, and
Typing really fast.

Introduction

Important submission note: For full credit:

  • Submit with Phases 1 and 2 complete by Thursday, February 22, worth 1 pt.
  • Submit with all phases complete by Tuesday, February 27.

Try to attempt the problems in order, as some later problems will depend on earlier problems in their implementation and therefore also when running ok tests.

The entire project can be completed with a partner.

You can get 1 bonus point by submitting the entire project by Monday, February 26.

In this project, you will write a program that measures typing speed. Additionally, you will implement typing autocorrect, which is a feature that attempts to correct the spelling of a word after a user types it. This project is inspired by typeracer.

Final Product

Our staff solution to the project can be interacted with at cats.cs61a.org. If you'd like, feel free to try it out now. When you finish the project, you'll have implemented a significant part of this yourself!

Download Starter Files

You can download all of the project code as a zip archive. This project includes several files, but your changes will be made only to cats.py. Here are the files included in the archive:

  • cats.py: The typing test logic.
  • utils.py: Utility functions for interacting with files and strings.
  • ucb.py: Utility functions for CS 61A projects.
  • data/sample_paragraphs.txt: Text samples to be typed. These are scraped Wikipedia articles about various subjects.
  • data/common_words.txt: Common English words in order of frequency.
  • data/words.txt: Many more English words in order of frequency.
  • data/final_diff_words.txt: Even more English words!
  • data/testcases.out: Test cases for the optional Final Diff extension.
  • cats_gui.py: A web server for the web-based graphical user interface (GUI).
  • gui_files: A directory of files needed for the graphical user interface (GUI).
  • multiplayer: A directory of files needed to support multiplayer mode.
  • favicons: A directory of icons.
  • images: A directory of images.
  • ok, proj02.ok, tests: Testing files.
  • score.py: Part of the optional Final Diff extension.

Logistics

The project is worth 20 points. 19 points are for correctness and 1 point is for submitting Phases 1 & 2 by the checkpoint date.

You will turn in the following files:

  • cats.py

You do not need to modify or turn in any other files to complete the project. To submit the project, submit the required files to the appropriate Gradescope assignment.

For the functions that we ask you to complete, there may be some initial code that we provide. If you would rather not use that code, feel free to delete it and start from scratch. You may also add new function definitions as you see fit.

However, please do not modify any other functions or edit any files not listed above. Doing so may result in your code failing our autograder tests. Also, please do not change any function signatures (names, argument order, or number of arguments).

Throughout this project, you should be testing the correctness of your code. It is good practice to test often, so that it is easy to isolate any problems. However, you should not be testing too often, to allow yourself time to think through problems.

We have provided an autograder called ok to help you with testing your code and tracking your progress. The first time you run the autograder, you will be asked to log in with your Ok account using your web browser. Please do so. Each time you run ok, it will back up your work and progress on our servers.

The primary purpose of ok is to test your implementations.

If you want to test your code interactively, you can run

 python3 ok -q [question number] -i
with the appropriate question number (e.g. 01) inserted. This will run the tests for that question until the first one you failed, then give you a chance to test the functions you wrote interactively.

You can also use the debugging print feature in OK by writing

 print("DEBUG:", x)
which will produce an output in your terminal without causing OK tests to fail with extra output.

Getting Started Videos

To see these videos, you should be logged into your berkeley.edu email.

Phase 1: Typing

Problem 1 (1 pt)

Throughout the project, we will be making changes to functions in cats.py.

Implement pick. This function selects which paragraph the user will type. It takes three parameters:

  • a list of paragraphs (strings) called paragraphs
  • a select function, which returns True for paragraphs that can be selected
  • a non-negative index k

The pick function returns the kth paragraph for which select returns True. If no such paragraph exists (because k is too large), then pick returns the empty string.

Before writing any code, unlock the tests to verify your understanding of the question:

python3 ok -q 01 -u

Once you are done unlocking, begin implementing your solution. You can check your correctness with:

python3 ok -q 01

Problem 2 (1 pt)

Implement about, which takes a list of subject words. It returns a function which takes a paragraph and returns a boolean indicating whether that paragraph contains any of the words in subject.

Once we've implemented about, we'll be able to pass the returned function to pick as the select argument, which will be useful as we continue to implement our typing test.

To be able to make this comparison accurately, you will need to ignore case (that is, assume that uppercase and lowercase letters don't change what word it is) and punctuation in the paragraph. Additionally, only check for exact matches of the words in subject in the paragraph, not substrings. For example, "dogs" is not a match for the word "dog".

Hint: Use the split, lower, and remove_punctuation functions in utils.py.

Before writing any code, unlock the tests to verify your understanding of the question:

python3 ok -q 02 -u

Once you are done unlocking, begin implementing your solution. You can check your correctness with:

python3 ok -q 02

Problem 3 (2 pts)

Implement accuracy, which takes a typed paragraph and a source paragraph. It returns the percentage of words in typed that exactly match the corresponding words in source. Case and punctuation must match as well. "Corresponding" here means that two words must occur at the same indices in typed and source; the first words of both must match, the second words of both must match, and so on.

A word in this context is any sequence of characters separated from other words by whitespace, so treat "dog;" as a single word.

If typed is longer than source, then the extra words in typed that have no corresponding word in source are all incorrect.

If both typed and source are empty, then the accuracy is 100.0. If typed is empty but source is not empty, then the accuracy is zero. If typed is not empty but source is empty, then the accuracy is zero.

Before writing any code, unlock the tests to verify your understanding of the question:

python3 ok -q 03 -u

Once you are done unlocking, begin implementing your solution. You can check your correctness with:

python3 ok -q 03

Problem 4 (1 pt)

Implement wpm, which computes the words per minute, a measure of typing speed, given a string typed and the amount of elapsed time in seconds. Despite its name, words per minute is not based on the number of words typed, but instead the number of groups of 5 characters, so that a typing test is not biased by the length of words. The formula for words per minute is the ratio of the number of characters (including spaces) typed divided by 5 (a typical word length) to the elapsed time in minutes.

For example, the string "I am glad!" contains ten characters (not including the quotation marks). The words per minute calculation uses 2 as the number of words typed (because 10 / 5 = 2). If someone typed this string in 30 seconds (half a minute), their speed would be 4 words per minute.

Before writing any code, unlock the tests to verify your understanding of the question:

python3 ok -q 04 -u

Once you are done unlocking, begin implementing your solution. You can check your correctness with:

python3 ok -q 04

Time to test your typing speed! You can use the command line to test your typing speed on paragraphs about a particular subject. For example, the command below will load paragraphs about cats or kittens. See the run_typing_test function for the implementation if you're curious (but it is defined for you).

python3 cats.py -t cats kittens

You can try out the web-based graphical user interface (GUI) using the following command. (You may have to use Ctrl+C or Cmd+C on your terminal to quit the GUI after you close the tab in your browser).

python3 cats_gui.py

Phase 2: Autocorrect

In the web-based GUI, there is an autocorrect button, but right now it doesn't do anything. Let's implement automatic correction of typos. Whenever the user presses the space bar, if the last word they typed doesn't match a word in the dictionary but is close to one, then that similar word will be substituted for what they typed.

Problem 5 (2 pts)

Implement autocorrect, which takes a typed_word, a word_list, a diff_function, and a limit. The goal of autocorrect is to return the word in word_list that is closest to the provided typed_word.

Specifically, autocorrect does the following:

  • If the typed_word is contained inside the word_list, autocorrect returns that word.
  • Otherwise, autocorrect returns the word from word_list that has the lowest difference from the provided typed_word based on the diff_function.
  • However, if the lowest difference between typed_word and any of the words in word_list is greater than limit, then typed_word is returned instead. That is, limit puts a "limit" on how bad of a typo can be corrected.

Note: Assume that typed_word and all elements of word_list are lowercase and have no punctuation.

Important: If multiple strings in word_list are tied for the lowest difference from typed_word, autocorrect should return the string that appears closest to the front of word_list.

A diff function takes in three arguments. The first is the typed_word, the second is the source word (in this case, a word from word_list), and the third argument is the limit. The output of the diff function, which is a number, represents the amount of difference between the two strings.

Here is an example of a diff function that computes the minimum of 1 + limit and the difference in length between the two input strings:

>>> def length_diff(w1, w2, limit):
...     return min(limit + 1, abs(len(w2) - len(w1)))
>>> length_diff('mellow', 'cello', 10)
1
>>> length_diff('hippo', 'hippopotamus', 5)
6

Hint: Try using max or min with the optional key argument (which takes in a one-argument function). For example, max([-7, 2, -1], key = abs) would return -7 since abs(-7) is greater than abs(2) and abs(-1).

Before writing any code, unlock the tests to verify your understanding of the question:

python3 ok -q 05 -u

Once you are done unlocking, begin implementing your solution. You can check your correctness with:

python3 ok -q 05

Problem 6 (3 pts)

Implement feline_fixes, which is a diff function that takes two strings. It returns the minimum number of characters that must be changed in the typed word in order to transform it into the source word. If the strings are not of equal length, the difference in lengths is added to the total.

Here are some examples:

>>> big_limit = 10
>>> feline_fixes("nice", "rice", big_limit)    # Substitute: n -> r
1
>>> feline_fixes("range", "rungs", big_limit)  # Substitute: a -> u, e -> s
2
>>> feline_fixes("pill", "pillage", big_limit) # Don't substitute anything, length difference of 3.
3
>>> feline_fixes("goodbye", "good", big_limit) # Don't substitute anything, length difference of 3.
3
>>> feline_fixes("roses", "arose", big_limit)  # Substitute: r -> a, o -> r, s -> o, e -> s, s -> e
5
>>> feline_fixes("rose", "hello", big_limit)   # Substitute: r->h, o->e, s->l, e->l, length difference of 1.
5

Important: You may not use while, for, or list comprehensions in your implementation. Use recursion.

If the number of characters that must change is greater than limit, then feline_fixes should return any number larger than limit and should minimize the amount of computation needed to do so.

Why is there a limit? We know that autocorrect will reject any source word whose difference with the typed word is greater than limit. It doesn't matter if the difference is greater than limit by 1 or by 100; autocorrect will reject it just the same. Therefore, as soon as we know the difference will be above limit, it makes sense to try to minimize extra computation, even if the returned difference won't be exactly correct.

These two calls to feline_fixes should take about the same amount of time to evaluate:

>>> limit = 4
>>> feline_fixes("roses", "arose", limit) > limit
True
>>> feline_fixes("rosesabcdefghijklm", "arosenopqrstuvwxyz", limit) > limit
True

To ensure that you are correctly minimizing the amount of extra computation that is performed after the limit is reached, there is an autograder test that measures the performance of your solution based on the number of function calls that it makes. The test isn't perfect; using a helper function may cause this test to fail even if you are successfully avoiding extra computation.

Before writing any code, unlock the tests to verify your understanding of the question:

python3 ok -q 06 -u

Once you are done unlocking, begin implementing your solution. You can check your correctness with:

python3 ok -q 06

Try turning on autocorrect in the GUI. Does it help you type faster? Are the corrections accurate?

Problem 7 (3 pts)

Implement minimum_mewtations, which is a diff function that returns the minimum number of edit operations needed to transform the typed word into the source word.

There are three kinds of edit operations, with some examples:

  1. Add a letter to typed.

    • Adding "k" to "itten" gives us "kitten".
  2. Remove a letter from typed.

    • Removing "s" from "scat" givs us "cat".
  3. Substitute a letter in typed for another.

    • Substituting "z" with "j" in "zaguar" gives us "jaguar".

Each edit operation contributes 1 to the difference between two words.

>>> big_limit = 10
>>> minimum_mewtations("cats", "scat", big_limit)       # cats -> scats -> scat
2
>>> minimum_mewtations("purng", "purring", big_limit)   # purng -> purrng -> purring
2
>>> minimum_mewtations("ckiteus", "kittens", big_limit) # ckiteus -> kiteus -> kitteus -> kittens
3

We have provided a template of an implementation in cats.py. You may modify the template however you want or delete it entirely.

Hint: This is a recursive function with three recursive calls. One of these recursive calls will be similar to the recursive call in feline_fixes. Additionally, you will need more than one base case to solve this problem.

If the number of edits required is greater than limit, then minimum_mewtations should return any number larger than limit and should minimize the amount of computation needed to do so.

These two calls to minimum_mewtations should take about the same amount of time to evaluate:

>>> limit = 2
>>> minimum_mewtations("ckiteus", "kittens", limit) > limit
True
>>> minimum_mewtations("ckiteusabcdefghijklm", "kittensnopqrstuvwxyz", limit) > limit
True

To ensure that you are correctly minimizing the amount of extra computation that is performed after the limit is reached, there is an autograder test that measures the performance of your solution based on the number of function calls that it makes.

Before writing any code, unlock the tests to verify your understanding of the question:

python3 ok -q 07 -u

Once you are done unlocking, begin implementing your solution. You can check your correctness with:

python3 ok -q 07

Try typing again. Are the corrections more accurate?

python3 cats_gui.py

Submit your Phase 1 and Phase 2 Checkpoint

Check to make sure that you completed all the problems in Phase 1 and Phase 2A:

python3 ok --score

Then, submit cats.py to the Cats Checkpoint assignment on Gradescope before the checkpoint deadline.

When you run ok commands, you'll still see that some tests are locked because you haven't completed the whole project yet. You'll get full credit for the checkpoint if you complete all the problems up to this point.

(Optional) Extension: Final Diff (0 pts)

You may optionally design your own diff function called final_diff. Here are some ideas for making even more accurate corrections:

  • Take into account which additions and deletions are more likely than others. For example, it's much more likely that you'll accidentally leave out a letter if it appears twice in a row.
  • Treat two adjacent letters that have swapped positions as one change, not two.
  • Try to incorporate common misspellings.

You can also set the limit you'd like your diff function to use by changing the value of the variable FINAL_DIFF_LIMIT in cats.py.

You can check your final_diff's success rate by running:

 python3 score.py

If you don't know where to start, try copy-pasting your code for feline_fixes and minimum_mewtations into final_diff and scoring them. Looking at the typos they accidentally fixed might give you some ideas!

Phase 3: Multiplayer

Typing is more fun with friends! You'll now implement multiplayer functionality, so that when you run cats_gui.py on your computer, it connects to the course server at cats.cs61a.org and looks for someone else to race against.

To race against a friend, 5 different programs will be running:

  • Your GUI, which is a program that handles all the text coloring and display in your web browser.
  • Your cats_gui.py, which is a web server that communicates with your GUI using the code you wrote in cats.py.
  • Your opponent's cats_gui.py.
  • Your opponent's GUI.
  • The CS 61A multiplayer server, which matches players together and passes messages around.

When you type, your GUI uploads what you have typed to your cats_gui.py server, which computes how much progress you have made and returns a progress update. It also uploads a progress update to the multiplayer server, so that your opponent's GUI can display it.

Meanwhile, your GUI display is always trying to keep current by asking for progress updates from cats_gui.py, which in turn requests that info from the multiplayer server.

Each player has an id number that is used by the server to track typing progress.

Problem 8 (2 pts)

Implement report_progress, which is called every time the user finishes typing a word. It takes a list of the words typed, a list of the words in the source, the user's user_id, and a upload function that is used to upload a progress report to the multiplayer server. There will never be more words in typed than in source.

Your progress is a ratio of the words in the source that you have typed correctly, up to the first incorrect word, divided by the number of source words. For example, this example has a progress of 0.25:

report_progress(["Hello", "ths", "is"], ["Hello", "this", "is", "wrong"], ...)

Your report_progress function should do two things: upload a message to the multiplayer server and return the progress of the player with user_id.

You can upload a message to the multiplayer server by calling the upload function on a two-element dictionary containing the keys 'id' and 'progress'. You should then return the player's progress, which is the ratio of words you computed.

Hint: See the dictionary below for an example of a potential input into the upload function. This dictionary represents a player with user_id 1 and progress 0.6.

{'id': 1, 'progress': 0.6}

Before writing any code, unlock the tests to verify your understanding of the question:

python3 ok -q 08 -u

Once you are done unlocking, begin implementing your solution. You can check your correctness with:

python3 ok -q 08

Problem 9 (2 pts)

Implement time_per_word, which takes in a list words and timestamps_per_player, a list of lists for each player with timestamps indicating when each player finished typing every individual word in words. It returns a match with the given information.

A match is a data abstraction that represents a typing "match" between multiple players. Speficially, each match stores the instance variables words and times.

  • The times are stored as a list of lists of how long it took each player to type every word in words.
  • Specifically, times[i][j] indicates how long it took player i to type words[j].

For example, say words = ['Hello', 'world'] and times = [[5, 1], [4, 2]], then [5, 1] corresponds to the list of times for player 0, and [4, 2] corresponds to the list of times for player 1. Thus, player 0 took 5 units of time to write the word 'Hello'.

Important: Be sure to use the match constructor when returning a match. The tests will check that you are using the match data abstraction rather than assuming a particular data format.

For more information, you can read the definitions for the match constructor below or in cats.py. However, as with any data abstraction, we are only concerned with what our functions do rather than their specific implementations!

def match(words, times):
    """A data abstraction containing all words typed and their times.

    Arguments:
        words: A list of strings, each string representing a word typed.
        times: A list of lists for how long it took for each player to type
            each word.
            times[i][j] = time it took for player i to type words[j].

    Example input:
        words: ['Hello', 'world']
        times: [[5, 1], [4, 2]]
    """
    assert all([type(w) == str for w in words]), 'words should be a list of strings'
    assert all([type(t) == list for t in times]), 'times should be a list of lists'
    assert all([isinstance(i, (int, float)) for t in times for i in t]), 'times lists should contain numbers'
    assert all([len(t) == len(words) for t in times]), 'There should be one word per time.'
    return {"words": words, "times": times}

def get_word(match, word_index):
    """A utility function that gets the word with index word_index"""
    assert 0 <= word_index < len(get_all_words(match)), "word_index out of range of words"
    return get_all_words(match)[word_index]

def time(match, player_num, word_index):
    """A utility function for the time it took player_num to type the word at word_index"""
    assert word_index < len(get_all_words(match)), "word_index out of range of words"
    assert player_num < len(get_all_times(match)), "player_num out of range of players"
    return get_all_times(match)[player_num][word_index]

def get_all_words(match):
    """A selector function for all the words in the match"""
    return match["words"]

def get_all_times(match):
    """A selector function for all typing times for all players"""
    return match["times"]

def match_string(match):
    """A helper function that takes in a match data abstraction and returns a string representation of it"""
    return f"match({get_all_words(match)}, {get_all_times(match)})"

Timestamps are cumulative and always increasing, while the values in times are differences between consecutive timestamps for each player.

Here's an example: If timestamps_per_player = [[1, 3, 5], [2, 5, 6]], the corresponding times attribute of the match would be [[2, 2], [3, 1]]. This is because the differences in timestamps are (3-1), (5-3) for the first player and (5-2), (6-5) for the second player. The first value of each list within timestamps_per_player represents the initial starting time for each player.

Before writing any code, unlock the tests to verify your understanding of the question:

python3 ok -q 09 -u

Once you are done unlocking, begin implementing your solution. You can check your correctness with:

python3 ok -q 09

Problem 10 (2 pts)

Implement fastest_words, which returns which words each player typed fastest. This function is called once all players have finished typing. It takes in a match.

Specifically, the fastest_words function returns a list of lists of words, one list for each player, and within each list the words they typed the fastest (against all the other players). In the case of a tie, consider the earliest player in the list (the smallest player index) to be the one who typed it the fastest.

For example consider the following match with the words 'Just', 'have', and 'fun'. Player 0 typed 'fun' the fastest (3 seconds), Player 1 typed 'Just' the fastest (4 seconds), and they tied on the word 'have' (both took 1 second) so we consider to Player 0 to be the fastest, because they are the earliest player in the list.

>>> player_0 = [5, 1, 3]
>>> player_1 = [4, 1, 6]
>>> fastest_words(match(['Just', 'have', 'fun'], [player_0, player_1]))
[['have', 'fun'], ['Just']]

The match argument is a match data abstraction, just like the one we returned in Problem 9.

  • You can access words in a match with the selector get_word, which takes in a match and the word_index (an integer).
  • In addition, you can access the time it took a player to type the word at a particular index using the time function, which takes takes an integer player_num, in addition to match and word_index.
  • With these two functions and a match, we can easily access the time it took any player to type any word!
>>> player_0 = [5, 1, 3]
>>> player_1 = [4, 1, 6]
>>> ex_match = match(['Just', 'have', 'fun'], [player_0, player_1])
>>> get_word(ex_match, 2)
'fun'
>>> time(ex_match, 0, 2)
3

Important: Be sure to use the match selectors when using a match. The tests will check that you are using the match data abstraction rather than assuming a particular data format.

Make sure your implementation does not mutate the given player input lists. For the example above, calling fastest_words on [player_0, player_1] should not mutate player_0 or player_1.

Before writing any code, unlock the tests to verify your understanding of the question:

python3 ok -q 10 -u

Once you are done unlocking, begin implementing your solution. You can check your correctness with:

python3 ok -q 10

Congratulations! Now you can play against other students in the course. Set enable_multiplayer to True near the bottom of cats.py and type swiftly!

python3 cats_gui.py

Project Submission

Run ok on all problems to make sure all tests are unlocked and pass:

python3 ok

You can also check your score on each part of the project:

python3 ok --score

Once you are satisfied, submit this assignment by uploading cats.py to the Cats assignment on Gradescope. For a refresher on how to do this, refer to Lab 00.

You can add a partner to your Gradescope submission by clicking on + Add Group Member under your name on the right hand side of your submission. Only one partner needs to submit to Gradescope.
