Discussion 4: Tree Recursion, Trees, Python Lists
Getting Started
In this discussion, don't use a Python interpreter to run code until you are confident your solution is correct. Figure things out and check your work by thinking about what your code will do. Not sure? Talk to your group!
[Note] Recursion takes practice. Please don't get discouraged if you're struggling to write recursive functions. Instead, every time you do solve one (even with help or in a group), make note of what you had to realize to make progress. Students improve through practice and reflection.
[For Fun] This emoticon of a guy in a cowboy hat is valid Python: o[:-D]
>>> o = [2, 0, 2, 4]
>>> [ o[:-D] for D in range(1,4) ]
[[2, 0, 2], [2, 0], [2]]
ðŸ¤
Tree Recursion
For the following questions, don't start trying to write code right away. Instead, start by describing the recursive case in words. Some examples:
- In
fib
from lecture, the recursive case is to add together the previous two Fibonacci numbers. - In
double_eights
from lab, the recursive case is to check for double eights in the rest of the number. - In
count_partitions
from lecture, the recursive case is to partitionn-m
using parts up to sizem
and to partitionn
using parts up to sizem-1
.
In case you need a refresher on Tree Recursion, you can use the section below (dropdown if you're on the website)
For example, this is the Virahanka-Fibonacci sequence:
0, 1, 1, 2, 3, 5, 8, 13, ...
.
Each term is the sum of the previous two terms. This tree-recursive function calculates the n
th Virahanka-Fibonacci number.
def virfib(n):
if n == 0 or n == 1:
return n
return virfib(n - 1) + virfib(n - 2)
Calling virfib(6)
results in a call structure that resembles
an upside-down tree (where f
is virfib
):
Each recursive call f(i)
makes a call to f(i-1)
and a call to f(i-2)
.
Whenever we reach an f(0)
or f(1)
call, we can directly return 0
or 1
without making more recursive calls. These calls are our base cases.
A base case returns an answer without depending on the results of other calls. Once we reach a base case, we can go back and answer the recursive calls that led to the base case.
As we will see, tree recursion is often effective for problems with branching choices. In these problems, you make a recursive call for each branching choice.
Q1: Insect Combinatorics
An insect is inside an m
by n
grid. The insect starts at the bottom-left corner (1, 1)
and wants to end up at the top-right corner (m, n)
. The insect can only move up or to the right. Write a function paths
that takes the height and width of a grid and returns the number of paths the insect can take from the start to the end. (There is a closed-form solution to this problem, but try to answer it with recursion.)
In the 2
by 2
grid, the insect has two paths from the start to the end. In the 3
by 3
grid, the insect has six paths (only three are shown above).
Your Answer Run in 61A CodeHint: What happens if the insect hits the upper or rightmost edge of the grid?
def paths(m, n):
"""Return the number of paths from one corner of an
M by N grid to the opposite corner.
>>> paths(2, 2)
2
>>> paths(5, 7)
210
>>> paths(117, 1)
1
>>> paths(1, 157)
1
"""
if m == 1 or n == 1:
return 1
return paths(m - 1, n) + paths(m, n - 1)
# Base case: Look at the two visual examples given. Since the insect
# can only move to the right or up, once it hits either the rightmost edge
# or the upper edge, it has a single remaining path -- the insect has
# no choice but to go straight up or straight right (respectively) at that point.
# There is no way for it to backtrack by going left or down.
The recursive case is that there are paths from the square to the right through an (m, n-1) grid and paths from the square above through an (m-1, n) grid.
Lists
Some of you already know list operations that we haven't covered yet,
such as append
. Don't use those today. All you need are list literals (e.g.,
[1, 2, 3]
), item selection (e.g., s[0]
), list addition (e.g., [1] + [2,
3]
), len
(e.g., len(s)
), and slicing (e.g., s[1:]
). Use those! There will be plenty of time for other list
operations when we introduce them next week.
The most important thing to remember about lists is that a non-empty list s
can be split into its first element s[0]
and the rest of the list s[1:]
.
There are two forms:
[<expression> for <element> in <sequence>]
[<expression> for <element> in <sequence> if <conditional>]
Here's an example that starts with [1, 2, 3, 4]
, picks out the even elements
2
and 4
using if i % 2 == 0
, then squares each of these using i*i
. The
purpose of for i
is to give a name to each element in [1, 2, 3, 4]
.
>>> [i*i for i in [1, 2, 3, 4] if i % 2 == 0]
[4, 16]
This list comprehension evaluates to a list of:
- The value of
i*i
- For each element
i
in the sequence[1, 2, 3, 4]
- For which
i % 2 == 0
In other words, this list comprehension will create a new list that contains
the square of every even element of the original list [1, 2, 3, 4]
.
We can also rewrite a list comprehension as an equivalent for
statement,
such as for the example above:
>>> result = []
>>> for i in [1, 2, 3, 4]:
... if i % 2 == 0:
... result = result + [i*i]
>>> result
[4, 16]
>>> s = [2, 3, 6, 4]
>>> s[0]
2
>>> s[1:]
[3, 6, 4]
Q2: Even weighted
Write a function that takes a list s
and returns a new list that keeps only
the even-indexed elements of s
and multiplies them by their corresponding
index. First approach this problem with a normal for
loop (without list comprehension).
def even_weighted_loop(s):
"""
>>> x = [1, 2, 3, 4, 5, 6]
>>> even_weighted_loop(x)
[0, 6, 20]
"""
result = []
for i in range(len(s)):
if i % 2 == 0:
result = result + [i * s[i]]
return result
Now that you’ve done it with a for
loop, try it with a list comprehension!
def even_weighted_comprehension(s):
"""
>>> x = [1, 2, 3, 4, 5, 6]
>>> even_weighted_comprehension(x)
[0, 6, 20]
"""
return [i * s[i] for i in range(len(s)) if i % 2 == 0]
The key point to note is that instead of iterating over each element in the list, we must instead iterate over the indices of the list. Otherwise, there's no way to tell if we should keep a given element.
If you get stuck, ask for help!
Trees
A tree
is a data structure that represents a hierarchy of information. A file system is a good example of a tree structure. For example, within your cs61a
folder, you have folders separating your projects
, lab
assignments, and homework
. The next level is folders that separate different assignments, hw01
, lab01
, hog
, etc., and inside those are the files themselves, including the starter files and ok
. Below is an incomplete diagram of what your cs61a
directory might look like.
As you can see, unlike trees in nature, the tree abstract data type is drawn with the root at the top and the leaves at the bottom.
For a tree t
:
- Its root label can be any value, and
label(t)
returns it. - Its branches are trees, and
branches(t)
returns a list of branches. - An identical tree can be constructed with
tree(label(t), branches(t))
. - You can call functions that take trees as arguments, such as
is_leaf(t)
. - That's how you work with trees. No
t == x
ort[0]
orx in t
orlist(t)
, etc. - There's no way to change a tree (that doesn't violate an abstraction barrier).
Here's an example tree t1
, for which its branch branches(t1)[1]
is t2
.
t2 = tree(5, [tree(6), tree(7)])
t1 = tree(3, [tree(4), t2])
tree
, label
, and branches
are implemented in
order to use them correctly, but here is the implementation from lecture.
def tree(label, branches=[]):
for branch in branches:
assert is_tree(branch), 'branches must be trees'
return [label] + list(branches)
def label(tree):
return tree[0]
def branches(tree):
return tree[1:]
def is_leaf(tree):
return not branches(tree)
def is_tree(tree):
if type(tree) != list or len(tree) < 1:
return False
for branch in branches(tree):
if not is_tree(branch):
return False
return True
Q3: Has Path
Implement has_path
, which takes a tree t
and a list p
. It returns whether
there is a path from the root of t
with labels p
. For example, t1
has a
path from its root with labels [3, 5, 6]
but not [3, 4, 6]
or [5, 6]
.
Important: Before trying to implement this function, discuss these questions from lecture about the recursive call of a tree processing function:
- What recursive calls will you make?
- What type of values do they return?
- What do the possible return values mean?
- How can you use those return values to complete your implementation?
If you get stuck, you can view our answers to these questions by clicking the hint button below, but please don't do that until your whole group agrees.
As you usual, you will call has_path
on each branch b
. You'll make this
call after comparing p[0]
to label(t)
, and so the second argument to
has_path
will be the rest of p
: has_path(b, p[1:])
.
What type of values do they return?
has_path
always returns a bool
value: True
or False
.
What do the possible return values mean?
If has_path(b, p[1:])
returns True
, then there is a path through branch b
for which p[1:]
are the node labels.
How can you use those return values to complete your implementation?
If you have already checked that label(t)
is equal to p[0]
, then a True
return value means there is a path through t
with labels p
using that branch
b
. A False
value means there is no path through that branch, but there
might be path through a different branch.
def has_path(t, p):
"""Return whether tree t has a path from the root with labels p.
>>> t2 = tree(5, [tree(6), tree(7)])
>>> t1 = tree(3, [tree(4), t2])
>>> has_path(t1, [5, 6]) # This path is not from the root of t1
False
>>> has_path(t2, [5, 6]) # This path is from the root of t2
True
>>> has_path(t1, [3, 5]) # This path does not go to a leaf, but that's ok
True
>>> has_path(t1, [3, 5, 6]) # This path goes to a leaf
True
>>> has_path(t1, [3, 4, 5, 6]) # There is no path with these labels
False
"""
if p == [label(t)]:
return True
elif label(t) != p[0]:
return False
else:
return any([has_path(b, p[1:]) for b in branches(t)])
The base case expression p == [label(t)]
checks two things: that p
has one item and that the item is equal to label(t)
. Longer expressions (that don't fit the template) would also work, such as if len(p) == 1 and p[0] == label(t)
.
The recursive case expresses that if a path through some branch b
is labeled
p[1:]
, then there is a path through t
labeled p
.
If your group needs some guidance, you can click on the hints below, but please talk with your group first before reading the hints.
p
is a list of length one with the
label of t
as its only element. The second base case should check if the
first element of p
matches the label of t
.
p[0]
is equal to label(t)
, and so all that's left to check is that p[1:]
contains the labels in a path through one of the branches. One way is with
this template:
for ____:
if ____:
return True
return False
Discussion Time! Can the else
case of has_path
be written in just one
line? Why or why not? You can ignore how fast the function will run.
Q4: Find Path
Implement find_path
, which takes a tree t
with unique labels and a value
x
. It returns a list containing the labels of the nodes along a path from the
root of t
to a node labeled x
.
If x
is not a label in t
, return None
. Assume that the labels of t
are unique.
First talk through how to make and use the recursive call. (Try it yourselves; don't just click the hint button. That's how you learn.)
find_path(b, x)
on each branch b
.
What type of values do they return?
Each recursive call will either return None
or a non-empty list of node labels.
What do the possible return values mean?
If find_path(b, x)
returns None
, then x
does not appear in b
. If
find_path(b, x)
returns a list, then it contains the node labels for a path
through b
that ends with the node labeled x
.
How can you use those return values to complete your implementation?
If a list is returned, then it contains all of the labels in the path except
label(t)
, which must be placed at the front.
def find_path(t, x):
"""
>>> t2 = tree(5, [tree(6), tree(7)])
>>> t1 = tree(3, [tree(4), t2])
>>> find_path(t1, 5)
[3, 5]
>>> find_path(t1, 4)
[3, 4]
>>> find_path(t1, 6)
[3, 5, 6]
>>> find_path(t2, 6)
[5, 6]
>>> print(find_path(t1, 2))
None
"""
if label(t) == x:
return [label(t)]
for b in branches(t):
path = find_path(b, x)
if path:
return [label(t)] + path
return None
[label(t)]
creates a one-element list of the labels along a path that starts at the root of t
and also ends there, since the root is labeled x
.
The assignment path = find_path(b, x)
allows the return value of this recursive call to be used twice: once to check if it's None
(which is a false value) and again to build a longer list.
The expression [label(t)] + path
for a tree t
and list path
creates a longer list that starts with the label of t
and continues with the elements of path
.
Please don't view the hints until you've discussed with your group and can't make progress.
x
is the label of t
, then return a list with one element that contains the label of t
.
path
to the result of a
recursive call to find_path(b, x)
so that you can both check whether it's
None
and extend it if it's a list.
For a list path
and a value v
, the expression [v] + path
creates a longer
list that starts with v
and then has the elements of path
.
Description Time! When your group has completed this question, it's time to
describe why this function does not have a base case that uses is_leaf
. Come
up with an explanation as a group and pick someone to present your answer.
Q5: Sprout Leaves
Define a function sprout_leaves
that takes in a tree, t
, and a list of
leaf labels, leaves
. It produces a new tree that is identical to t
, but where each
old leaf node has new branches, for each label in leaves
.
For example, suppose we have the tree t = tree(1, [tree(2), tree(3, [tree(4)])])
. Calling
sprout_leaves(t, [5, 6])
produces the following tree:
def sprout_leaves(t, leaves):
"""Sprout new leaves containing the labels in leaves at each leaf of
the original tree t and return the resulting tree.
>>> t1 = tree(1, [tree(2), tree(3)])
>>> print_tree(t1)
1
2
3
>>> new1 = sprout_leaves(t1, [4, 5])
>>> print_tree(new1)
1
2
4
5
3
4
5
>>> t2 = tree(1, [tree(2, [tree(3)])])
>>> print_tree(t2)
1
2
3
>>> new2 = sprout_leaves(t2, [6, 1, 2])
>>> print_tree(new2)
1
2
3
6
1
2
"""
if is_leaf(t):
return tree(label(t), [tree(leaf) for leaf in leaves])
return tree(label(t), [sprout_leaves(s, leaves) for s in branches(t)])
Submit Attendance
You're done! Excellent work this week. Please be sure to ask your section TA for the attendance form link and fill it out for credit. (one submission per person per section).
Extra Practice
Q6: Tree Deciphering
What value is bound to result
?
result = label(min(branches(max([t1, t2], key=label)), key=label))
Solution
6: max([t1, t2], key=label)
evaluates to the t2
tree because its label 5 is
larger than t1
's label 3. Among t2
's branches (which are leaves), the left one
labeled 6 has a smaller label.
How convoluted! (That's a big word.)
Here's a quick refresher on how key
functions work with max
and min
,
max(s, key=f)
returns the item x
in s
for which f(x)
is largest.
>>> s = [-3, -5, -4, -1, -2]
>>> max(s)
-1
>>> max(s, key=abs)
-5
>>> max([abs(x) for x in s])
5
Therefore, max([t1, t2], key=label)
returns the tree with the largest label,
in this case t2
.
In case you're wondering, this expression does not violate an abstraction
barrier. [t1, t2]
and branches(t)
are both lists (not trees), and so it's
fine to call min
and max
on them.
